Motorized bicycles and mopeds are
the simplest, most comfortable, and most affordable motor
vehicles.
Buy and ride Soviet motorized
bicycles!
The 16 B motorized bicycle is
suitable for business and private trips and excursions in a wide
variety of road conditions; it is the simplest and most
affordable motor vehicle.
Thanks to its simple design, even
beginners can easily learn to ride it without any difficulty.
Motorized bicycles can also be ridden with pedals like regular
bicycles.
The simple, economical engine
allows a speed of up to 50 km/h.
Large wheels with wide tires and
the well-sprung saddle make road irregularities barely
noticeable. Due to the wheel support, the engine can be started
when the wheel is stationary.
The motorized bicycles are
finished in colorful enamel with pinstriping. The bare parts are
high-gloss chrome-plated. Standard accessories include a wind
generator with headlight, a tool set, an air pump, and a bell.
Simple construction and
first-class materials ensure trouble-free operation and a long
service life for the machine. |
Engine type...Single-cylinder
two-stroke carburetor
engine with crankcase scavenging. Model
A-4 (D-4)
Cylinder bore,
mm.............................. 38
Piston stroke,
mm.............................. 40
Displacement,
cm³.............................. 45
Compression ratio..............................
5.2
Rated power at 4000-4500 rpm,
hp........... 1
Fuel....mixture of gasoline and
automotive oil in the ratio, by quantity, 20 parts gasoline to
one part oil
Fuel consumption per 100 km road
distance at
20 km/h average speed, l......
maximum 1.5
Tank capacity,
l.................................... 2.3
Engine lubrication...................mixture
lubrication
Ignition type...................................magneto
ignition
Power transmission from engine
to rear wheel...........via roller
chain
Gear ratio
from crankshaft to drive sprocket.............4.2
: 1
Chain drive ratio....................................4.1 : 1
Clutch.........Twin-disc friction
clutch, semi-dry |
|
